A Primer on Diaphragm Design

This MCA manual provides the supporting theory, load tables, relevant problems, and illustrations regarding connection details for roof or wall diaphragm assemblies. The scope of the work includes a variety of material connections: elevated side flat fastening, top flat fastening, bottom flat fastening, fastening to wood, aluminum and steel as well as structural members and fastening of exposed cladding. This manual provides an extremely valuable design tool to professionals in the metal construction industry.
